AMS1117-3.3
The adjustable and fixed voltage regulators of the AMS1117 series are designed to deliver 1A output current and function down to 1V input-to-output difference. The device's dropout voltage is guaranteed to be 1.3V at maximum output current, dropping at lower load currents. Trimming on-chip adjusts the reference voltage to one percent. The current limit is also reduced, reducing stress on the regulator and energy source circuitry under overload conditions. The AMS1117 devices are pin compatible with existing three-terminal SCSI regulators and are available in low-profile surface mount SOT-223 packages, 8L SOIC packages, and TO-252 (DPAK) plastic packages.
AP2112K-3.3TRG1
The AP2112 is a guaranteed 600mA (min.) continuous load current, low dropout linear regulator in CMOS technology with enable function.
The fixed output voltage options for the AP2112 are 1.2V, 1.8V, 2.5V, 2.6V, or 3.3V. The LDO offers exceptional performance for coping with line and load transients because to its output precision of 1.5 percent and extremely quick loop response. The AP2112 has an auto discharge feature that, when the device is turned off, connects the output to earth through 60 ohms of resistance.
The regulator offers SOT25, SOT89-5, and SO-8 packaging and has a low power consumption. Previously known as SOT-23-5, SOT-89-5, and SOIC-8 packages, respectively, they have been renamed to conform to the most recent terminology used by Diodes Incorporated.
Features
Output voltage precision: 1.5 percent
600 mA is the output current (Min.)
Protection Against Foldback Short Current: 50mA
Enable the VOUT On/Off Function
@IOUT = 600mA Low Dropout Voltage (3.3V): 250mV (Typ.)
Excellent Line Regulation: 0.02 percent /V and 0.2 percent /A (Typ.) for the load regulation (Typ.)
Low Quiescent Current (Typ.): 55 A; Low Standby Current (Standard): 0.01 A (Typ.)
50VRMS Low Output Noise
OTSD Protection; PSRR: 100Hz -65dB, 1kHz -65dB
AP7165-SPG-13
Features of AP7165-SPG-13
? 2.2V to 5.5V, a broad input voltage range
? 500mA load with a 300mV very low dropout
? Extremely low quiescent current (IQ): typically 125 A
? Total accuracy is less than 2.5% for line, load, and temperature
? 0.8V to 5.0V adjustable output voltage range
? Extremely quick transient reaction
? A high PSRR.
? Reliable voltage control
? Current restriction and short circuit defence
? Thermal shut-off safeguards
? Stable with output capacitors of any kind up to 4.7 F
? A temperature range of -40 to +85 degrees Celsius.
? "Green" molding compound is available in U-DFN3030-10 and SO-8EP (No Br, Sb)
? RoHS Compliant and Lead Free Finish
Application of AP7165-SPG-13
- Servers and laptops
- Smart phone and PDA
- MP3/MP4
- Bluetooth headset
- Low and medium power applications
- FPGA and DSP core or I/O power
APQ8009-0-504NSP-TR-01-1-AA
Features of APQ8009
- Adreno 304 GPU 3D graphics accelerator with support for the newest API (up to 456 MHz)
- Battery-friendly audio/video use cases are provided by the Hexagon 536 DSP.
- Heterogeneous architecture features a quad-core, 32-bit Arm Cortex-A7 CPU with a maximum clock speed of 1.3GHz.
- Made using the cutting-edge 28 nm LP CMOS manufacturing method
- Integrated Bluetooth 4.1 low energy, GPS, and 802.11a/b/g/n support
- Offers specialized support for popular codecs in the market as well as additional multimedia formats to enable carrier deployments worldwide.
- An international network of QTI suppliers, users, programmers, and embedded device OEMs
- Wireless Speakers
- Cellular cameras
- Audiovisual Equipment
- Smart home technology
- Smart Home Devices
- Digital helpers
APT5020BVFR
Power MOS V? is a new generation of high voltage N-Channel enhancement
mode power MOSFETs. This new technology minimizes the JFET effect,
increases packing density and reduces the on-resistance. Power MOS V?
also achieves faster switching speeds through optimized gate layout.
? Fast Recovery Body Diode ? 100% Avalanche Tested
? Lower Leakage ? Popular TO-247 Package
? Faster Switching
