3296W 1K 102 Potentiometer

Electrical Characteristics of 3296W 1K  102 Potentiometer

• The typical resistance range is between 10 ohms and 2 megohms.
• The resistance tolerance range is 10% standard. Additionally, tighter tolerance is offered.
• The greatest Absolute Minimum Resistance is 2 ohms or about 1 percent, whichever is larger.
• Maximum Contact Resistance Variation is 3 Ohms or 1.0 percent, whichever is larger.

Adjustability of 3296W 1K

• The voltage range is 0.01 percent.
• Resistance levels are between 0.05 percent
• Infinite Insulation is the solution. Resistance is 1,000 Mohms minimum at 500 VDC.
• At sea level, the dielectric strength is around 900 vac, while at 70,000 feet, it is approximately 350 vac.

Environmental Characteristics of 3296W 1K

• At 70 °C, the power rating (300 volts maximum) is 0.5 watt; at 125 °C, it is 0 watt.
• A temperature range of -55 °C to 125 °C is included.
• 100 ppm/°C is the range of the temperature coefficient.
• Fluor inert seal test at 85 °C
• According to MIL-STD-202 Method, the humidity is 103.
